Hamilton Ultra Maxi-Duty Dual-Wheel Swivel Caster with 18" x 5" Nylast Wheel with 2" Precision Ball Bearing Hamilton

Hamilton Ultra Maxi-Duty Dual-Wheel Swivel Caster with 18" x 5" Nylast Wheel with 2" Precision Ball Bearing

Volume discounts applied at checkout

50-99 units: 5% Off
100-199 units: 10% Off
200+ units: 15% Off

.price-ui--loading { display: block !important; opacity: 1 !important; }

$15,132.00 USD

Status: In Stock

Most in-stock items ship same or next business day. Shipping rates shown at checkout.

PRODUCT CODE: S-UMD2-185NYB

Product Overview

Hamilton Ultra Maxi-Duty Dual-Wheel Swivel Caster with 18" x 5" Nylast Wheel with 2" Precision Ball Bearing

Introducing the Hamilton Caster Part#: S-UMD2-185NYB – the ultimate solution for heavy-duty mobility needs. Designed to effortlessly handle loads of up to 40,000 lbs, this caster is a true powerhouse when it comes to industrial applications.

Crafted with precision and built to last, the Hamilton Caster Part#: S-UMD2-185NYB guarantees exceptional performance even in the most demanding environments. Its robust construction ensures superior durability and reliability, making it an ideal choice for heavy-duty industrial equipment, manufacturing facilities, warehouses, and more.

With its exceptional weight capacity, this caster provides the strength and stability required to transport heavy loads with ease. The precision-machined swivel raceway allows for smooth and effortless maneuverability, ensuring optimal performance across various terrains.

The Hamilton Caster Part#: S-UMD2-185NYB features a top plate design for easy installation and secure attachment to your equipment. The plate is engineered to distribute weight evenly, minimizing stress points and maximizing stability during transport. This caster effortlessly navigates tight spaces and turns, enabling efficient movement within your facility.

Designed with safety in mind, the Hamilton Caster Part#: S-UMD2-185NYB boasts a high-quality polyurethane wheel that provides excellent traction and reduces the risk of slippage. The non-marking material ensures it won't leave unsightly marks or damage your floors, making it suitable for a wide range of indoor applications.

The Hamilton Caster Part#: S-UMD2-185NYB is the ultimate choice for heavy-duty mobility, offering unbeatable strength, durability, and reliability. Invest in this caster and experience seamless movement of your heaviest loads like never before.

Technical Specs

Swivel or Rigid caster Swivel
Load Capacity (lbs.) @ 3 mph 40000
Wheel Diameter (in.) 18
Overall Height (in.) 23.625
Swivel Offset (in.) 4
Mounting Plate (in.) 14 x 14
Bolt Hole 1 (in.) 12 x 12
Mounting Bolt (in.) .75
Caster Color/Finish Platinum Enamel
Wheel Type Nylast
Wheel Color/Finish Charcoal Gray
Bearing Type Precision Sealed Ball
Wheel Material @ Tread Nylon
Shipping Weight (lbs.) 400
Caster Rig Type Integral Forged Kingpin
Number of Wheels in Caster 2
Mounting Plate Length (in.) 14
Mounting Plate Width (in.) 14
Wheel Core Material Nylon

Key Features

Maximum weight capacity: 40,000 lbs
Robust construction for durability and reliability
Precision-machined swivel raceway for smooth maneuverability
Top plate design for easy installation
Even weight distribution for enhanced stability
Effortless navigation in tight spaces and turns
High-quality polyurethane wheel for excellent traction
Non-marking material to protect floors
