Heavy Duty Casters · 500 to 3,000 lb Per Caster · 3-1/4" to 10"

Custom made to order. All sales final.

Each Hamilton product is custom manufactured for your order (lead time is shown on each product page). Please confirm all specs before checkout, since made-to-order items aren't eligible for returns, exchanges or refunds. Need help? Call 844-439-4335 or email info@casterhq.com and we'll verify fit for you.

This collection holds Heavy Duty casters with Duralast polyurethane, metal and ergonomic polyurethane wheels, built for shop carts, equipment, and material handling carts that move heavier loads. Casters in this collection range from 410 to 2,500 lb per caster. Wheels in this category range from 4 up to 10 inches in diameter with 2 to 3 in tread widths. The collection includes swivel and rigid models. Kingpinless swivels hold up better under shock and repeat loads. Dual wheel casters split the load over two wheels and swivel with less effort under heavy loads. Duralast polyurethane treads are quiet, protect floors, and carry heavy loads with low rolling effort. Metal wheels roll with low effort and handle debris and heat. They are loud and can mark finished floors. Choose swivel casters when the cart must turn in place and rigid casters for straight travel. Polyurethane aisle: polyurethane casters. Wheel hub: replacement wheels.

Shop by type

6 types

Wheel = wheel diameter · capacity is per caster.

Heavy Duty Casters: buying guide

Hamilton heavy duty casters in polyurethane, cast iron and phenolic, 3-1/4 to 10 in wheels, rated 500 to 3,000 lb per caster.

Diameter 3-1/4 to 10 inTread 2, 2-1/2 and 3 inPlate 4-1/2 x 6-1/2 in (most)500 to 3,000 lb per caster

Hamilton heavy duty casters by tread

Tread	Core	Wheel sizes	Rated per caster	Listed temperature	Where it fits
Polyurethane	Cast iron and Aluminum	3-1/4 to 10 in	575 to 2,500 lb	-5°F to 160°F	quiet, floor-friendly and long wearing
Cast iron		4, 5, 6, 8 and 10 in	1,000 to 2,500 lb	-40°F to 320°F	heat, chips and heavy loads on rough floors
Phenolic		3-1/4 to 10 in	700 to 2,400 lb	Up to 250°F	hard and easy rolling on smooth, dry floors
Nylon		4, 5, 6 and 8 in	1,000 to 3,000 lb	-30°F to 220°F	low rolling effort on smooth floors, handles wet areas
Steel		4, 5, 6, 8 and 10 in	1,400 to 3,000 lb	-22°F to 750°F	heavy loads and track
Rubber	Cast iron	6, 8 and 10 in	500 to 1,000 lb	-30°F to 160°F	cushioned and quiet on finished floors

Ratings are for single casters of Hamilton heavy duty casters, from product fields [S1].

Wheel sizes

Wheel	Treads	Rated
4 x 2 in	polyurethane, nylon and cast iron	450 to 2,000 lb
5 x 2 in	polyurethane, steel and cast iron	600 to 2,000 lb
6 x 2 in	polyurethane, phenolic and nylon	410 to 2,300 lb
6 x 2-1/2 in	phenolic, cast iron and steel	540 to 3,200 lb
6 x 3 in	polyurethane, nylon and steel	680 to 3,200 lb
8 x 2 in	polyurethane, nylon and phenolic	500 to 2,500 lb
8 x 3 in	polyurethane, steel and rubber	840 to 3,200 lb
10 x 3 in	polyurethane, rubber and cast iron	1,000 to 3,200 lb

Choosing Hamilton heavy duty casters

Load: divide the loaded weight by three for a four-caster cart [S2]. A 2,000 lb caster from this page then suits about 6,000 lb, and the strongest at 3,000 lb about 9,000 lb.
Mount: most Hamilton heavy duty casters use a 4-1/2 x 6-1/2 in top plate; 4 x 4-1/2 in and 5 x 7 in plates are listed too; check the bolt spacing on your frame against the plate size.
Floor: on Hamilton heavy duty casters, polyurethane and rubber are kinder to tile and finished floors; cast iron, phenolic, nylon and steel roll easier under heavy loads on smooth concrete.
Rig: rigid and swivel Hamilton heavy duty casters are listed.
Heat: among Hamilton heavy duty casters, the highest listed range is -22°F to 750°F on steel; check the temperature field on each listing before oven or hot-room use.

Hamilton heavy duty casters questions

How much weight can Hamilton heavy duty casters carry?

Single Hamilton heavy duty casters are rated 500 to 3,000 lb; most fall between 1,000 and 2,000 lb.

What top plate do Hamilton heavy duty casters use?

Most Hamilton heavy duty casters use 4-1/2 x 6-1/2 in. Others listed: 4 x 4-1/2 in and 5 x 7 in.

What wheel material is most common on Hamilton heavy duty casters?

Polyurethane leads on Hamilton heavy duty casters, rated 575 to 2,500 lb per caster. Cast iron is next at 1,000 to 2,500 lb.

Jordan Wilson, CasterHQ · reviewed October 20, 2026 · 844-439-4335 · info@casterhq.com

Sources

[S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
[S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
