2-1/2" x 1" Casters & Wheels · Industrial-Rated Small-Equipment Size

This collection holds 2-1/2 in x 1 in Casters with rubber, polyolefin and cast iron wheels, built for light carts, racks, and stands. Casters in this collection range from 95 to 250 lb per caster. Wheels in this category are 2-1/2 inches in diameter with 1 in tread width. The collection includes swivel, rigid, and brake models. Rubber wheels are quiet, cushion the load, and protect floors. Semi steel and iron wheels roll with low effort and handle debris and heat. They are loud and can mark finished floors. Polyolefin is light, low cost, and resists water and many chemicals. It is hard, so it is loud on rough floors. Plate and stem mounts are listed on each product so you can match bolt pattern or stem size before you order. Choose swivel casters when the cart must turn in place and rigid casters for straight travel. Rubber aisle: rubber casters. Wheel hub: replacement wheels.

2-1/2" x 1" Casters & Wheels: buying guide

2-1/2 x 1 in casters in rubber, cast iron and polyolefin, 2-1/2 in wheels, rated 95 to 200 lb per caster.

Diameter 2-1/2 inTread 1 inPlate 2-3/8 x 3-5/8 in95 to 200 lb per caster

2-1/2 x 1 in casters by tread

Tread Core Wheel sizes Rated per caster Listed temperature Where it fits
Rubber 2-1/2 in 95 to 115 lb -40°F to 160°F cushioned and quiet on finished floors
Cast iron 2-1/2 in 200 lb -40°F to 320°F heat, chips and heavy loads on rough floors
Polyolefin 2-1/2 in 115 lb -45°F to 180°F wet and chemical areas, light to medium loads

Ratings are for single casters of 2-1/2 x 1 in casters, from product fields [S1].

Choosing 2-1/2 x 1 in casters

  1. Load: plan on three casters carrying a four-caster cart [S2]; at 115 lb each, a common rating here, that is about 345 lb, and the 200 lb top rating covers about 600 lb.
  2. Mount: most 2-1/2 x 1 in casters use a 2-3/8 x 3-5/8 in top plate; 2-3/4 x 3-3/4 in plates are listed too; check the bolt spacing on your frame against the plate size.
  3. Floor: on 2-1/2 x 1 in casters, rubber is kinder to tile and finished floors; cast iron and polyolefin roll easier under heavy loads on smooth concrete.
  4. Rig: rigid and swivel 2-1/2 x 1 in casters are listed.
  5. Heat: among 2-1/2 x 1 in casters, the highest listed range is -40°F to 320°F on cast iron; check the temperature field on each listing before oven or hot-room use.

2-1/2 x 1 in casters questions

How much weight can 2-1/2 x 1 in casters carry?

Single 2-1/2 x 1 in casters are rated 95 to 200 lb.

What top plate do 2-1/2 x 1 in casters use?

Most 2-1/2 x 1 in casters use 2-3/8 x 3-5/8 in. Others listed: 2-3/4 x 3-3/4 in.

What wheel material is most common on 2-1/2 x 1 in casters?

Rubber leads on 2-1/2 x 1 in casters, rated 95 to 115 lb per caster. Cast iron is next at 200 lb.

Are replacement wheels sold for 2-1/2 x 1 in casters?

Yes. Wheel-only listings for 2-1/2 x 1 in casters are here, sized 2-1/2 in; measure bore and hub length before you order.

Sources

  • [S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
  • [S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
