Nylon caster wheels handle heavy loads on smooth floors while resisting most chemicals, oils, and solvents. The hard, low-friction compound rolls easily under industrial loads and holds up to temperatures up to 250°F. Available in 2" to 8" diameters, rated 100 to 700 lbs per caster.
Nylon casters excel on smooth factory floors, machine shop environments, and anywhere chemical or oil exposure is present.
The low-friction surface and hard compound make nylon ideal for heavy-load carts that move constantly. Nylon does not absorb oils or solvents that would soften rubber wheels, making it the standard spec for metalworking, automotive, and chemical processing environments.
At loads above 400 lbs per caster, nylon typically outperforms polyurethane in chemical resistance and temperature stability.
Polyurethane has better floor protection and shock absorption. Nylon wins on chemical resistance, temperature range, and load capacity. For dry, smooth factory floors with heavy loads and chemical exposure, nylon is the right choice.
Standard nylon casters are rated to 250°F continuous service temperature.
This covers most factory environments, heated production floors, and proximity to ovens or heat sources at a safe distance. For temperatures above 250°F, specify high-temperature nylon or phenolic wheels, which handle 350°F to 550°F depending on compound.
Nylon is generally non-marking on most floor surfaces.
The off-white or gray compound does not leave rubber residue. On polished concrete or epoxy floors, nylon is commonly specified for its clean roll. For hospital or showroom use, verify with the specific floor manufacturer as very hard wheels can occasionally scuff soft finishes.
Load per caster = total equipment weight ÷ number of casters × 1.25 safety factor. For high-cycle applications (constant movement all day), increase safety factor to 1.5 and specify precision roller bearings — plain bore bearings overheat and fail under continuous heavy load.
| Spec | Value |
|---|---|
| Capacity Range | 100–300 lbs per caster |
| Wheel Diameter | 2", 3", or 4" |
| Wheel Width | 3/4"–1.25" |
| Bearing Type | Plain bore or roller |
| Best For | Parts carts, tool carts, lab equipment |
| Spec | Value |
|---|---|
| Capacity Range | 300–550 lbs per caster |
| Wheel Diameter | 5" or 6" |
| Wheel Width | 1.5"–2" |
| Bearing Type | Precision roller recommended |
| Best For | Industrial carts, die carts, chemical drums |
| Spec | Value |
|---|---|
| Capacity Range | 500–700 lbs per caster |
| Wheel Diameter | 8" |
| Wheel Width | 2"–2.5" |
| Bearing Type | Tapered roller |
| Best For | Heavy die carts, industrial equipment transport, chemical plants |
