06 Series

These 06 series casters use 5 x 1 in wheels for light carts, stands, and fixtures that need a bigger wheel to roll over thresholds. Casters in this collection range from 125 to 145 lb per caster. Treads include polyolefin, thermoplastic rubber, and soft rubber on a 2-3/8 x 3-5/8 in plate. Soft rubber or TPR tread is the better pick when the floor has chips or grit. Threaded stem, grip-ring, and expanding rubber stems for round and square tubing all appear on light-duty builds. Common uses include food service, bakeries, hospitals, schools, laboratories, and material handling carts. Match plate size and overall height before you order. Choose swivel casters when the cart must turn in place, rigid casters for straight travel, and add a brake when the cart needs to stay put. Capacities below are per caster unless a listing says set. Light duty hub: light duty casters. Cart aisle: cart casters.

Shop by type

1 type

Wheel = wheel diameter · capacity is per caster.

DuraStar 06 Series Top Plate…Wheel 4″–5″125–145 lb/caster20 styles

Durastar 06 series casters by tread

Tread	Core	Wheel sizes	Rated per caster	Listed temperature	Where it fits
Rubber	Polyolefin	4 and 5 in	125 to 145 lb	-40°F to 160°F	cushioned and quiet on finished floors
Polyolefin		4 and 5 in	140 to 145 lb	-45°F to 180°F	wet and chemical areas, light to medium loads
Polyurethane	Polyolefin	4 and 5 in	140 to 145 lb	-40°F to 180°F	quiet, floor-friendly and long wearing

Ratings are for single casters of Durastar 06 series casters, from product fields [S1].

Wheel sizes

Wheel	Treads	Rated
4 x 1 in	rubber, polyurethane and polyolefin	125 to 140 lb
5 x 1 in	rubber, polyolefin and polyurethane	130 to 145 lb

Choosing Durastar 06 series casters

Load: plan on three casters carrying a four-caster cart [S2]; Durastar 06 series casters rated 145 lb each then carry about 435 lb.
Mount: most Durastar 06 series casters use a 2-3/8 x 3-5/8 in top plate; match the bolt holes on your frame to the plate before ordering.
Floor: on Durastar 06 series casters, rubber and polyurethane are kinder to tile and finished floors; polyolefin rolls easier under heavy loads on smooth concrete.
Rig: swivel and rigid Durastar 06 series casters are listed.

Durastar 06 series casters questions

How much weight can Durastar 06 series casters carry?

Single Durastar 06 series casters are rated 125 to 145 lb; most fall between 130 and 145 lb.

What top plate do Durastar 06 series casters use?

Most Durastar 06 series casters use 2-3/8 x 3-5/8 in.

What wheel material is most common on Durastar 06 series casters?

Rubber leads on Durastar 06 series casters, rated 125 to 145 lb per caster. Among Durastar 06 series casters, polyolefin is next at 140 to 145 lb.

Jordan Wilson, CasterHQ · reviewed October 20, 2026 · 844-439-4335 · info@casterhq.com

Sources

[S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
[S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
