Expanding Stem Casters for 7/8" ID Tube · 210–325 lb · Polyurethane & Rubber · Expanding Rubber Stem

These expanding stem casters for 7/8 in ID tube fit light carts, racks, and stands. Casters in this collection range from 250 to 350 lb per caster. Wheels are 3 to 5 x 1-1/4 polyurethane, TPR, and polyolefin in swivel and brake models. Expanding rubber stems press into round or square tubing and grip as the bolt is tightened. Softer polyurethane or soft rubber or TPR tread is the better pick when the floor has chips or grit. Common uses include food service, bakeries, hospitals, schools, laboratories, and material handling carts. Threaded stem, grip-ring, and expanding rubber stems for round and square tubing all appear on light-duty builds. Measure the inside diameter of the tube and order the matching expanding stem. Choose swivel casters when the cart must turn in place, rigid casters for straight travel, and add a brake when the cart needs to stay put. Stem aisle: expanding stem casters. Light duty hub: light duty casters.

Fits 7/8" Id Tube: buying guide

Video Guide Expanding Stem Casters for Square & Round Tubing

Casters for 7/8 in ID tube in rubber, polyurethane and polyolefin, 3 to 5 in wheels, rated 210 to 325 lb per caster.

Casters for 7/8 in ID tube by tread

Tread	Core	Wheel sizes	Rated per caster	Listed temperature	Where it fits
Rubber	Polyolefin	3, 3-1/2, 4 and 5 in	210 to 325 lb	-45°F to 180°F	cushioned and quiet on finished floors
Polyurethane	Polyolefin	3, 3-1/2, 4 and 5 in	250 to 300 lb	-45°F to 180°F	quiet, floor-friendly and long wearing
Polyolefin		3, 3-1/2, 4 and 5 in	230 to 300 lb	-45°F to 180°F	wet and chemical areas, light to medium loads
Phenolic		3, 4 and 5 in	300 lb	-45°F to 180°F	hard and easy rolling on smooth, dry floors

Ratings are for single casters of casters for 7/8 in ID tube, from product fields [S1].

Wheel sizes

Wheel	Treads	Rated
3 x 1-1/4 in	polyurethane, rubber and phenolic	250 to 300 lb
3-1/2 x 1-1/4 in	polyurethane, polyolefin and rubber	230 to 250 lb
3-1/2 x 1-5/16 in	rubber	210 to 250 lb
4 x 1-1/4 in	polyurethane, polyolefin and rubber	250 to 300 lb
5 x 1-1/4 in	polyurethane, rubber and polyolefin	300 to 325 lb
5 x 1-5/16 in	rubber	250 lb

Choosing casters for 7/8 in ID tube

Load: plan on three casters carrying a four-caster cart [S2]; at 300 lb each, a common rating here, that is about 900 lb, and the 325 lb top rating covers about 975 lb.
Stem: the most common stem on casters for 7/8 in ID tube is 7/8 in; measure thread size and length, or the tube inside diameter, on the old caster.
Floor: on casters for 7/8 in ID tube, rubber and polyurethane are kinder to tile and finished floors; polyolefin and phenolic roll easier under heavy loads on smooth concrete.
Rig: swivel casters for 7/8 in ID tube are listed.

Casters for 7/8 in ID tube questions

How much weight can casters for 7/8 in ID tube carry?

Single casters for 7/8 in ID tube are rated 210 to 325 lb; most fall between 250 and 300 lb.

What stem do casters for 7/8 in ID tube use?

Most casters for 7/8 in ID tube list 7/8 in.

What wheel material is most common on casters for 7/8 in ID tube?

Rubber leads on casters for 7/8 in ID tube, rated 210 to 325 lb per caster. Polyurethane is next at 250 to 300 lb.

Jordan Wilson, CasterHQ · reviewed October 20, 2026 · 844-439-4335 · info@casterhq.com

Sources

[S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
[S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
