Rubber Wheels (All Types)

Diameter: 3 to 20 inTread: 2, 3 and 5 inPlate: 4 x 4-1/2 inCapacity: 100 to 8,600 lb per wheel
This page lists rubber wheels (all types) with rubber, cast iron, polyolefin and nylon treads. Rubber on cast iron and polyolefin cores is the most common tread on these rubber wheels (all types), rated 100 to 6,200 lb per wheel in 3 to 20 in. Ratings by tread: cast iron 3,400 to 8,600 lb, polyolefin 240 to 550 lb and nylon 300 to 1,200 lb. Complete casters are listed too, rated 300 to 840 lb each. Brands: Hamilton, Durastar, P&H and Blickle.

Rubber wheels (all types) by tread

Tread Core Wheel sizes Rated per wheel Listed temperature Where it fits
Rubber Cast iron and Polyolefin 3 to 20 in 100 to 6,200 lb -30°F to 160°F cushioned and quiet on finished floors
Cast iron Steel 15, 16, 18 and 20 in 3,400 to 8,600 lb 0°F to 175°F heat, chips and heavy loads on rough floors
Polyolefin 3-1/2 to 10 in 240 to 550 lb -40°F to 180°F wet and chemical areas, light to medium loads
Nylon 4 to 12 in 300 to 1,200 lb Up to 180°F low rolling effort on smooth floors, handles wet areas
Polyurethane Aluminum 6 and 8 in 300 to 500 lb -30°F to 250°F quiet, floor-friendly and long wearing

Ratings are for single wheels of rubber wheels (all types), from product fields [S1].

Wheel sizes

Wheel Treads Rated
4 x 2 in rubber, polyolefin and nylon 200 to 450 lb
5 x 1-1/4 in rubber and polyolefin 250 to 325 lb
5 x 2 in rubber, polyolefin and nylon 250 to 500 lb
6 x 2 in rubber, polyolefin and polyurethane 300 to 700 lb
8 x 2 in rubber, polyurethane and polyolefin 400 to 2,400 lb
10 x 2-1/2 in rubber and nylon 790 to 1,000 lb
12 x 2-1/2 in rubber and nylon 900 to 1,200 lb
16 x 5 in rubber and cast iron 2,570 to 4,700 lb

Choosing rubber wheels (all types)

  1. Load: divide the loaded weight by three for a four-wheel cart [S2]. Among rubber wheels (all types), a 1,600 lb wheel then suits about 4,800 lb, and the strongest at 8,600 lb about 25,800 lb.
  2. Mount: most rubber wheels (all types) use a 4 x 4-1/2 in top plate; match the bolt holes on your frame to the plate before ordering.
  3. Floor: on rubber wheels (all types), rubber and polyurethane are kinder to tile and finished floors; cast iron, polyolefin and nylon roll easier under heavy loads on smooth concrete.
  4. Rig: swivel rubber wheels (all types) are listed.

Rubber wheels (all types) questions

How much weight can rubber wheels (all types) carry?

Single rubber wheels (all types) are rated 100 to 8,600 lb; most fall between 410 and 1,600 lb.

What top plate do rubber wheels (all types) use?

Most rubber wheels (all types) use 4 x 4-1/2 in.

What wheel material is most common on rubber wheels (all types)?

Rubber leads on rubber wheels (all types), rated 100 to 6,200 lb per wheel. Among rubber wheels (all types), cast iron is next at 3,400 to 8,600 lb.

Are complete casters listed with rubber wheels (all types)?

Yes. Complete casters are on this page too, rated 300 to 840 lb each; compare the wheel size and bore with your rubber wheels (all types) before ordering.

Sources

  • [S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
  • [S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
