Up to 350 lbs
Up to 7,000 lbs
Up to 16,000 lbs
Up to 40,000 lbs
Shock absorbing
Outdoor / rough terrain
View All Specialty Casters
Browse all specialty caster types
All measurements indicate the wheel diameter by the tread width.
The below capacity ranges indicate the working (dynamic) load that each caster will support. A safety factor should be included in your formula to determine your required load rating per caster.
W/(C-1)=R W is total weight needed to move. C is total number of casters required. R is ideal load rating, with safety factor built in. Divide the total load weight by one less caster than you will use to safely determine load rating.
Plate dimensions shown are overall mounting plate size.
When replacing existing casters, select the closest plate size and verify bolt-hole compatibility.
BHP = Bolt Hole Pattern, shown under each plate.
Wheel = wheel diameter · capacity is per caster.
























| Tread | Core | Wheel sizes | Rated per caster | Listed temperature | Where it fits |
|---|---|---|---|---|---|
| Polyurethane | Polyolefin | 3, 3-1/2, 4 and 5 in | 250 to 350 lb | -45°F to 180°F | quiet, floor-friendly and long wearing |
| Rubber | Polyolefin | 3, 3-1/2, 4, 5 and 6 in | 175 to 325 lb | -40°F to 160°F | cushioned and quiet on finished floors |
| Phenolic | 3, 3-1/2, 4 and 5 in | 350 lb | Up to 250°F | hard and easy rolling on smooth, dry floors | |
| Polyolefin | 3, 4 and 5 in | 250 to 325 lb | -45°F to 180°F | wet and chemical areas, light to medium loads | |
| Nylon | 3, 4 and 5 in | 300 to 350 lb | -45°F to 200°F | low rolling effort on smooth floors, handles wet areas |
Ratings are for single casters of Durastar S24 series casters, from product fields [S1].
| Wheel | Treads | Rated |
|---|---|---|
| 3 x 1-1/4 in | polyurethane, rubber and polyolefin | 175 to 350 lb |
| 3-1/2 x 1-1/4 in | polyurethane, rubber and phenolic | 250 to 350 lb |
| 4 x 1-1/4 in | rubber, polyurethane and polyolefin | 220 to 350 lb |
| 5 x 1-1/4 in | rubber, polyurethane and polyolefin | 250 to 350 lb |
| 6 x 1-1/4 in | rubber | 325 lb |
Single Durastar S24 series casters are rated 175 to 350 lb; most fall between 275 and 350 lb.
Polyurethane leads on Durastar S24 series casters, rated 250 to 350 lb per caster. Among Durastar S24 series casters, rubber is next at 175 to 325 lb.
