All measurements indicate the wheel diameter by the tread width.
The below capacity ranges indicate the working (dynamic) load that each caster will support. A safety factor should be included in your formula to determine your required load rating per caster.
W/(C-1)=R W is total weight needed to move. C is total number of casters required. R is ideal load rating, with safety factor built in. Divide the total load weight by one less caster than you will use to safely determine load rating.
Plate dimensions shown are overall mounting plate size.
When replacing existing casters, select the closest plate size and verify bolt-hole compatibility.
BHP = Bolt Hole Pattern, shown under each plate.
Custom made to order. All sales final.
Each Hamilton product is custom manufactured for your order (lead time is shown on each product page). Please confirm all specs before checkout, since made-to-order items aren't eligible for returns, exchanges or refunds. Need help? Call 844-439-4335 or email info@casterhq.com and we'll verify fit for you.
Wheel = wheel diameter · capacity is per wheel.
























| Tread | Core | Wheel sizes | Rated per wheel | Listed temperature | Where it fits |
|---|---|---|---|---|---|
| Polyurethane | 4, 5, 6, 8 and 10 in | 500 to 3,200 lb | -50°F to 180°F | quiet, floor-friendly and long wearing |
Ratings are for single wheels of Hamilton Unilast wheels, from product fields [S1].
| Wheel | Treads | Rated |
|---|---|---|
| 4 x 1-1/4 in | polyurethane | 500 lb |
| 4 x 2 in | polyurethane | 750 lb |
| 5 x 2 in | polyurethane | 900 lb |
| 6 x 2 in | polyurethane | 1,000 to 1,100 lb |
| 6 x 2-1/4 in | polyurethane | 2,200 lb |
| 8 x 2 in | polyurethane | 1,000 to 2,000 lb |
| 8 x 3 in | polyurethane | 3,000 lb |
| 10 x 3 in | polyurethane | 3,200 lb |
Related to Hamilton Unilast wheels: industrial casters, Hamilton unilast UY wheels and Hamilton unilast UY wheels.
Single Hamilton Unilast wheels are rated 500 to 3,200 lb; most fall between 750 and 1,500 lb.
Polyurethane leads on Hamilton Unilast wheels, rated 500 to 3,200 lb per wheel.
Jordan Wilson, CasterHQ · reviewed October 20, 2026 · 844-439-4335 · info@casterhq.com
