The below capacity ranges indicate the working (dynamic) load that each caster will support. A safety factor should be included in your formula to determine your required load rating per caster.

W/(C-1)=R W is total weight needed to move. C is total number of casters required. R is ideal load rating, with safety factor built in. Divide the total load weight by one less caster than you will use to safely determine load rating.

V-Chain Bridles

Capacity: up to 4,700 lb

V-Chain Bridles for heavy warehouse carts, die carts, and plant fixtures. Typical builds show industrial frames and capacities 4,700 lb. Size capacity from the heaviest corner load with shock margin, and keep overall height consistent across the set. Match bolt-hole spacing or stem diameter to the frame before you standardize a fleet. These heavy-duty options cover everyday heavy warehouse carts, die carts, and plant fixtures without jumping to extreme forged series.
