5" x 1.25" Phenolic Casters

Diameter: 5 inTread: 1-1/4 inCapacity: 350 lb eachPlate sizes: 2-3/8 x 3-5/8

Nine listings of the CasterHQ LD series 5 x 1-1/4 in phenolic caster on a 2-3/8 x 3-5/8 in plate, 6-1/4 in tall. Each caster is rated 350 lb and each set of four 1,400 lb. Singles come as swivel, rigid and swivel with top lock, and sets include side lock and front lock versions. The wheels are rated -50 to 250°F, roll easily on smooth concrete and resist oil and grease.

350 lbs

TieredPricing

5" X 1.25" Light Duty Phenolic Wheel - Swivel Caster - 350 lb cap. CasterHQ

In Stock · Same/Next Day

5" x 1.25" Phenolic Swivel Caster – 350 lb

Part # HQ1350S-PL1-PH

from $17.00

Volume pricing available

PhenolicPlate

Load rating

350 lbs

Size5" x 1-1/4"

Capacity350 lbs

WheelPhenolic

MountPlate 2-3/8" x 3-5/8"

TypeSwivel

More Details Less Details

Width 1-1/4"

Height 6-1/4"

Bolt Pattern 1-3/4" x 2-7/8"

Temp Range -50°F to 250°F

Rig Type Swivel

Brake No Brake

Frame Zinc Plated Steel

CasterHQ's 'LD' Series swivel casters with 5 inch Phenolic wheels feature a heat treated...

Shop Product

350 lbs

TieredPricing

5" X 1.25" Light Duty Phenolic Wheel - Rigid Caster - 350 lb Cap CasterHQ

In Stock · Same/Next Day

5" x 1.25" Phenolic Rigid Caster – 350 lb

Part # HQ1350R-PL1-PH

from $16.00

Volume pricing available

PhenolicPlate

Load rating

350 lbs

Size5" x 1-1/4"

Capacity350 lbs

WheelPhenolic

MountPlate 2-3/8" x 3-5/8"

TypeRigid

More Details Less Details

Width 1-1/4"

Height 6-1/4"

Bolt Pattern 1-3/4" x 2-7/8"

Temp Range -50°F to 250°F

Rig Type Rigid

Brake No Brake

Frame Zinc Plated Steel

CasterHQ's 'LD' Series Rigid casters with a 5 inch Phenolic wheel are ideal for...

Shop Product

350 lbs

TieredPricing

5" X 1.25" Light Duty Phenolic Wheel - Swivel Caster with Top Locking Brake - 350 lb cap. CasterHQ

In Stock · Same/Next Day

5" x 1.25" Phenolic Swivel Top Locking Brake Caster – 350 lb

Part # HQ1350S-PL1-PH-TLB

from $23.00

Volume pricing available

PhenolicPlate

Load rating

350 lbs

Size5" x 1-1/4"

Capacity350 lbs

WheelPhenolic

MountPlate 2-3/8" x 3-5/8"

TypeSwivel with Brake · Top Lock Brake

More Details Less Details

Width 1-1/4"

Height 6-1/4"

Bolt Pattern 1-3/4" x 2-7/8"

Temp Range -50°F to 250°F

Rig Type Swivel with Brake

Brake Top Lock Brake

Frame Zinc Plated Steel

CasterHQ's 'LD' Series swivel casters with 5 inch Phenolic wheels feature a heat treated...

Shop Product

350 lbs

TieredPricing

5" X 1.25" Light Duty Phenolic Wheel - 4 Locking Swivel Casters - Set of 4 - 1,400 lbs cap per set of 4 CasterHQ

In Stock · Same/Next Day

5" x 1.25" Phenolic Swivel Locking Caster · Model HQ1350S-PL1-PH-4SB · 1,400 lb set of 4

Part # HQ1350S-PL1-PH-4SB

from $89.00

Volume pricing available

PhenolicPlate

Load rating

350 lbs

Size5" x 1-1/4"

Capacity350 lbs

WheelPhenolic

MountPlate 2-3/8" x 3-5/8"

TypeSwivel with Brake · Side Lock Brake

More Details Less Details

Width 1-1/4"

Height 6-1/4"

Bolt Pattern 1-3/4" x 2-7/8"

Temp Range -50°F to 250°F

Rig Type Swivel with Brake

Brake Side Lock Brake

Frame Zinc Plated Steel

5" X 1.25" Light Duty Phenolic Wheel - 4 Locking Swivel Casters - Set...

Shop Product

350 lbs

TieredPricing

5" X 1.25" Light Duty Phenolic Wheel - 4 Front Locking Swivel Casters - Set of 4 - 1,400 lbs cap per set of 4 CasterHQ

In Stock · Same/Next Day

5" x 1.25" Phenolic Swivel Front Locking Caster · 1,400 lb set of 4

Part # HQ1350S-PL1-PH-4FSB

from $112.00

Volume pricing available

PhenolicPlate

Load rating

350 lbs

Size5" x 1-1/4"

Capacity350 lbs

WheelPhenolic

MountPlate 2-3/8" x 3-5/8"

TypeSwivel with Brake

More Details Less Details

Width 1-1/4"

Height 6-1/4"

Bolt Pattern 1-3/4" x 2-7/8"

Temp Range -50°F to 250°F

Rig Type Swivel with Brake

Brake No Brake

Frame Zinc Plated Steel

5" X 1.25" Light Duty Phenolic Wheel - 4 Front Locking Swivel Casters -...

Shop Product

1400 lbs

TieredPricing

In Stock · Same/Next Day

5" x 1.25" Phenolic Swivel & Rigid Caster Set · Model HQ1350S-PL1-PH-22R · 1,400 lb set of 4

Part # HQ1350S-PL1-PH-22R

from $67.00

Volume pricing available

PhenolicPlate

Load rating

1400 lbs

Size5" x 1-1/4"

Capacity1400 lbs

WheelPhenolic

MountPlate 2-3/8" x 3-5/8"

TypeSwivel, Rigid

More Details Less Details

Width 1-1/4"

Height 6-1/4"

Bolt Pattern 1-3/4" x 2-7/8"

Temp Range -50°F to 250°F

Rig Type Swivel, Rigid

Brake No Brake

Frame Zinc Plated Steel

5" X 1.25" Light Duty Phenolic Wheel - 2 Swivel Casters 2 Rigid -...

Shop Product

350 lbs

TieredPricing

5" X 1.25" Light Duty Phenolic Wheel - 2 Front Locking Casters 2 Rigid - Set of 4 - 1,400 lbs cap per set of 4 CasterHQ

In Stock · Same/Next Day

5" x 1.25" Phenolic Swivel & Locking Caster Set · Model HQ1350S-PL1-PH-2SB2S · 1,400 lb set of 4

Part # HQ1350S-PL1-PH-2SB2S

from $78.00

Volume pricing available

PhenolicPlate

Load rating

350 lbs

Size5" x 1-1/4"

Capacity350 lbs

WheelPhenolic

MountPlate 2-3/8" x 3-5/8"

TypeSwivel, Swivel with Brake · Side Lock Brake

More Details Less Details

Width 1-1/4"

Height 6-1/4"

Bolt Pattern 1-3/4" x 2-7/8"

Temp Range -50°F to 250°F

Rig Type Swivel, Swivel with Brake

Brake Side Lock Brake

Frame Zinc Plated Steel

5" X 1.25" Light Duty Phenolic Wheel - 2 Top Locking Swivel Casters &...

Shop Product

350 lbs

TieredPricing

5" X 1.25" Light Duty Phenolic Wheel - 2 Locking Casters 2 Rigid - Set of 4 - 1,400 lbs cap per set of 4 CasterHQ

In Stock · Same/Next Day

5" x 1.25" Phenolic Swivel & Rigid Caster Set · Model HQ1350S-PL1-PH-2SB2R · 1,400 lb set of 4

Part # HQ1350S-PL1-PH-2SB2R

from $77.00

Volume pricing available

PhenolicPlate

Load rating

350 lbs

Size5" x 1-1/4"

Capacity350 lbs

WheelPhenolic

MountPlate 2-3/8" x 3-5/8"

TypeSwivel with Brake, Rigid · Side Lock Brake

More Details Less Details

Width 1-1/4"

Height 6-1/4"

Bolt Pattern 1-3/4" x 2-7/8"

Temp Range -50°F to 250°F

Rig Type Swivel with Brake, Rigid

Brake Side Lock Brake

Frame Zinc Plated Steel

5" X 1.25" Light Duty Phenolic Wheel - 2 Locking Casters 2 Rigid -...

Shop Product

1400 lbs

TieredPricing

In Stock · Same/Next Day

5" x 1.25" Phenolic Swivel Caster – 1,400 lb Set of 4

Part # HQ1350S-PL1-PH-SCS4

from $89.00

Volume pricing available

PhenolicPlate

Load rating

1400 lbs

Size5" x 1-1/4"

Capacity1400 lbs

WheelPhenolic

MountPlate 2-3/8" x 3-5/8"

TypeSwivel

More Details Less Details

Width 1-1/4"

Height 6-1/4"

Bolt Pattern 1-3/4" x 2-7/8"

Temp Range -50°F to 250°F

Rig Type Swivel

Brake No Brake

Frame Zinc Plated Steel

5" X 1.25" Light Duty Phenolic Wheel - Swivel Caster Set of 4 -...

Shop Product

The nine listings

Listing	What you get	Rated load
Single swivel	1 swivel	350 lb
Single rigid	1 rigid	350 lb
Single swivel with top lock	1 swivel with top lock brake	350 lb
Set: all swivel	4 swivels	1,400 lb
Set: 2 swivel + 2 rigid	2 swivels, 2 rigids	1,400 lb
Set: 2 locking + 2 rigid	2 side lock swivels, 2 rigids	1,400 lb
Set: 2 locking + 2 swivel	2 locking swivels, 2 swivels	1,400 lb
Set: all locking	4 side lock swivels	1,400 lb
Set: front locking	4 front lock swivels	1,400 lb

Product fields and descriptions [S1]. Temperature -50 to 250°F on all nine.

What the LD series is

LD is the light-duty CasterHQ series: a zinc-plated steel rig with a heat treated ball bearing swivel raceway [S1]. The phenolic wheel is a hard molded resin, so it rolls with little effort and is not harmed by oil, grease or mild heat [S2].

Good fits

Shop carts, welding carts and parts carts on smooth concrete.
Light equipment that has to roll past warm machines, up to 250°F.
Carts that see oil or grease on the floor.

Watch for

Noise. Phenolic is hard and loud on rough floors.
Wet floors and washdown. Colson does not recommend phenolic where moisture is present [S3].
Floor debris. A hard wheel does not roll over chips and gravel well.

Other sizes: phenolic wheels and phenolic caster sets on a 4 x 4-1/2 in plate.

5 in phenolic caster questions

How much do 5 in phenolic casters hold?

350 lb per caster, 1,400 lb per set of four.

What temperature can they take?

The wheels are rated -50 to 250°F.

What plate do they use?

A 2-3/8 x 3-5/8 in top plate. Overall height is 6-1/4 in.

Are phenolic casters good on wet floors?

No. Phenolic is best on dry floors. For washdown, look at polyurethane or polyolefin wheels.

Jordan Wilson, CasterHQ · reviewed October 20, 2026 · 844-439-4335 · info@casterhq.com

Sources

[S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
[S2] Hamilton Caster, Industrial Caster Wheels overview and Phenolic & Polyolefin page (hamiltoncaster.com/Wheels): capacity range and use notes for each wheel family; phenolic is resin with macerated canvas, polyolefin is blended polymers such as polyethylene and polypropylene.
[S3] Colson D4 Defender stainless datasheet (colsoncaster.com): wheel material summary (rubber, polyurethane, nylon, phenolic, polyolefin).
