8" x 2" Casters

Custom made to order. All sales final.

Each Hamilton product is custom manufactured for your order (lead time is shown on each product page). Please confirm all specs before checkout, since made-to-order items aren't eligible for returns, exchanges or refunds. Need help? Call 844-439-4335 or email info@casterhq.com and we'll verify fit for you.

Diameter: 8 inTread: 2 inCapacity: 1,325 to 1,600 lb per casterPlate sizes: 4-1/2 x 6-1/2

This page lists four polyurethane casters with 8 in wheels, rated 1,325 to 1,600 lb each, made by Hamilton. Every one uses a 4-1/2 x 6-1/2 in top plate, and you can pick swivel or rigid and without brakes. Picks range from a Hamilton S-AEZFHS-8DB70-1 8 x 2 in Duralast XC swivel spring loaded caster rated 1,325 lb to a Hamilton S-AEZFHS-8DB70-2 8 x 2 in Duralast XC swivel spring loaded caster rated 1,600 lb.

1600 lbs

TieredPricing

Hamilton Aerospace S-AEZFHS-8DB70-2 Heavy Service Swivel Caster - 8" Duralast XC Polyurethane Wheel for Aerospace Industry Hamilton

Made to Order · 4-6 Wk

Hamilton S-AEZFHS-8DB70-2 8" x 2" Duralast XC Swivel Spring Loaded Caster

Part # S-AEZFHS-8DB70-2

from $1,303.00

Volume pricing available

PolyurethanePlate

Load rating

1600 lbs

Size8" x 2"

Capacity1600 lbs

WheelPolyurethane

MountPlate 4-1/2" x 6-1/2"

TypeSwivel

More Details Less Details

Width 2"

Height 10-1/2"

Bolt Pattern 2-7/16" x 4-15/16" and 3-3/8" x 5-1/4"

Core Cast Iron

Temp Range -5°F to 160°F

Rig Type Swivel

Brake No Brake

Frame Platinum Powder

S-AEZFHS-8DB70-2 Hamilton Aerospace Spring Loaded Heavy Service Swivel Caster 8" x 2" Duralast XC...

Shop Product

1325 lbs

TieredPricing

Hamilton Aerospace S-AEZFHS-8DB70-1: 8" x 2" Duralast XC Polyurethane Wheel - Heavy Service Swivel Caster with 1/2" Sealed Precision Bearings - Buy Top Aerospace Caster Technology Hamilton

Made to Order · 4-6 Wk

Hamilton S-AEZFHS-8DB70-1 8" x 2" Duralast XC Swivel Spring Loaded Caster – 1325 lb

Part # S-AEZFHS-8DB70-1

from $1,218.00

Volume pricing available

PolyurethanePlate

Load rating

1325 lbs

Size8" x 2"

Capacity1325 lbs

WheelPolyurethane

MountPlate 4-1/2" x 6-1/2"

TypeSwivel

More Details Less Details

Width 2"

Height 10-1/2"

Bolt Pattern 2-7/16" x 4-15/16" and 3-3/8" x 5-1/4"

Core Cast Iron

Temp Range -5°F to 160°F

Rig Type Swivel

Brake No Brake

Frame Platinum Powder

Buy S-AEZFHS-8DB70-1 Hamilton Aerospace Spring Loaded Heavy Service Swivel Caster 8" x 2" Duralast...

Shop Product

1600 lbs

TieredPricing

Hamilton Aerospace R-AEZFHS-8DB70-2 Heavy Service Rigid Caster - 8" Duralast XC Polyurethane Wheel for Aerospace Industry Hamilton

Made to Order · 4-6 Wk

Hamilton R-AEZFHS-8DB70-2 8" x 2" Duralast XC Rigid Spring Loaded Caster

Part # R-AEZFHS-8DB70-2

$1,276.00

Volume pricing available

PolyurethanePlate

Load rating

1600 lbs

Size8" x 2"

Capacity1600 lbs

WheelPolyurethane

MountPlate 4-1/2" x 6-1/2"

TypeRigid

More Details Less Details

Width 2"

Height 10-1/2"

Bolt Pattern 2-7/16" x 4-15/16" and 3-3/8" x 5-1/4"

Core Cast Iron

Temp Range -5°F to 160°F

Rig Type Rigid

Brake No Brake

Frame Platinum Powder

R-AEZFHS-8DB70-2 Hamilton Aerospace Spring Loaded Heavy Service Rigid Caster 8" x 2" Duralast XC...

Shop Product

1325 lbs

TieredPricing

Hamilton Aerospace R-AEZFHS-8DB70-1: 8" x 2" Duralast XC Polyurethane Wheel - Heavy Service Rigid Caster with 1/2" Sealed Precision Bearings - Buy Top Aerospace Caster Technology Hamilton

Made to Order · 4-6 Wk

Hamilton R-AEZFHS-8DB70-1 8" x 2" Duralast XC Rigid Caster – 1325 lb

Part # R-AEZFHS-8DB70-1

from $1,210.00

Volume pricing available

PolyurethanePlate

Load rating

1325 lbs

Size8" x 2"

Capacity1325 lbs

WheelPolyurethane

MountPlate 4-1/2" x 6-1/2"

TypeRigid

More Details Less Details

Width 2"

Height 10-1/2"

Bolt Pattern 2-7/16" x 4-15/16" and 3-3/8" x 5-1/4"

Core Cast Iron

Temp Range -5°F to 160°F

Rig Type Rigid

Brake No Brake

Frame Platinum Powder

Buy R-AEZFHS-8DB70-1 Hamilton Aerospace Spring Loaded Heavy Service Rigid Caster 8" x 2" Duralast...

Shop Product

Hamilton Spring Loaded | AEZFHS Caster with 6" Duralast XC Polyurethane Wheels

6" Duralast XC Polyurethane Wheel | Spring Loaded | AEZFHS Caster Design

State-of-the-Art Hamilton Casters for Advanced Mobility

Dive into the excellence of Hamilton's AEZFHS Spring Loaded Casters. Specifically crafted with a 6" Duralast XC Polyurethane Wheel, this caster guarantees top-notch performance and durability. Ideal for a range of heavy-duty applications, it ensures effortless mobility and prolonged service life.

Elevate Mobility with Hamilton’s Spring Loaded Casters

Experience the superiority of Hamilton's AEZFHS series. Perfectly engineered for demanding environments, this spring-loaded caster reduces wear, lowers maintenance needs, and enhances user experience. Trust Hamilton for unparalleled caster solutions.

Need Assistance? Hamilton’s Caster Experts are Ready to Help

Exploring the AEZFHS series for your setup? Connect with our adept Caster Specialists for personalized recommendations. Avail expert guidance weekdays between 8 am - 5 pm. Opt for Hamilton - your trusted partner in advanced caster technology.

BHP: 1-3/4″ × 2-7/8″, slotted to 3″

BHP: 1-3/4″ × 2-15/16″ slotted to 2-3/8″ × 3-3/8″

BHP: 2-5/8” X 3-5/8” (Slotted to 3” x 3”)

BHP: 2-7/16" x 4-15/16" slotted to 3-3/8" x 5-1/4"

(3″ Wide Casters), Industry-Standard

BHP: 3-3/8" x 5-1/4" slotted to 4-1/8" x 6-1/8"

BHP: 4-1/8" x 6" slotted to 4-1/2" x 6-1/8"
