Total Lock Stem Casters

These stem mount total lock casters lock both the wheel and the swivel so the cart stays put. Casters in this collection range from 190 to 350 lb per caster for most models. Wheels in this category range from 3 up to 5 in in polyurethane (poly or urethane), TPR, and rubber. Sets of 4 are rated 1,000 to 1,400 lb per set. Softer polyurethane or soft rubber or TPR tread is the better pick when the floor has chips or grit. Common uses include food service, bakeries, hospitals, schools, laboratories, and material handling carts. Threaded stem, grip-ring, and expanding rubber stems for round and square tubing all appear on light-duty builds. Match the stem type, thread, and length to the old caster before you order. Capacities below are per caster unless a listing says set. Read the listing for the exact wheel size, overall height, and mount shown. Total lock aisle: total locking casters. Stem aisle: stem casters.

Shop by caster type

6 types

Capacity shown is per caster (per wheel for wheels). How to measure a stem →

Total lock stem casters by tread

Tread Core Wheel sizes Rated per caster Listed temperature Where it fits
Polyurethane Polyolefin 3, 3-1/2, 4 and 5 in 250 to 350 lb -45°F to 180°F quiet, floor-friendly and long wearing
Rubber Polyolefin 3, 3-1/2, 4 and 5 in 190 to 1,400 lb cushioned and quiet on finished floors
Semi-steel 4 and 5 in 300 to 350 lb -45°F to 600°F rough floors, heat and heavy loads
Nylon 4 in 275 lb Up to 160°F low rolling effort on smooth floors, handles wet areas

Ratings are for single casters of total lock stem casters, from product fields [S1].

Wheel sizes

Wheel Treads Rated
3 x 1-1/4 in polyurethane and rubber 190 to 300 lb
3-1/2 x 1-1/4 in polyurethane and rubber 250 to 1,200 lb
4 x 1-1/4 in polyurethane, nylon and semi-steel 250 to 350 lb
5 x 1-1/4 in polyurethane, rubber and semi-steel 300 to 1,400 lb

Choosing total lock stem casters

  1. Load: plan on three casters carrying a four-caster cart [S2]; at 350 lb each, a common rating here, that is about 1,050 lb, and the 1,400 lb top rating covers about 4,200 lb.
  2. Stem: the most common stem on total lock stem casters is 1/2-13 x 1-1/2 in; 1/2-13 x 1 in also appear; measure thread size and length, or the tube inside diameter, on the old caster.
  3. Floor: on total lock stem casters, polyurethane and rubber are kinder to tile and finished floors; semi-steel and nylon roll easier under heavy loads on smooth concrete.
  4. Rig: swivel total lock stem casters are listed, with total lock brake options.
  5. Heat: among total lock stem casters, the highest listed range is -45°F to 600°F on semi-steel; check the temperature field on each listing before oven or hot-room use.

Total lock stem casters questions

How much weight can total lock stem casters carry?

Single total lock stem casters are rated 190 to 1,400 lb; most fall between 300 and 350 lb.

What stem do total lock stem casters use?

Most total lock stem casters list 1/2-13 x 1-1/2 in. Others: 1/2-13 x 1 in.

What wheel material is most common on total lock stem casters?

Polyurethane leads on total lock stem casters, rated 250 to 350 lb per caster. Rubber is next at 190 to 1,400 lb.

Sources

  • [S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
  • [S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
