8" x 3" Forged Steel Casters

Diameter: 6, 8, 10 inTread: 3 inCapacity: up to 2,775 lb
8" x 3" Forged Steel Casters for heavy warehouse carts, die carts, and plant fixtures. You will see wheel diameters 6, 8, 10 in, steel treads, and plate-mount frames across the SKUs listed below. Bring plate and stem measurements when replacing unmarked casters so the new corners sit level. Size capacity from the heaviest corner load with shock margin, and keep overall height consistent across the set.

Shop by type

3 types

Wheel = wheel diameter · capacity is per caster.

TieredPricing
Hamilton Aerospace S-AEZFFM-83FSB - 8"x3" Forged Steel Wheel Swivel Caster with 3/4" Precision Ball Bearing for Aerospace Applications Hamilton
Made to Order · 4-6 Wk
Hamilton S-AEZFFM-83FSB 8"x3" Forged Steel Swivel Spring Loaded Caster
Part # S-AEZFFM-83FSB
$1,783.00
Volume pricing available
Plate
Diameter 8"
Mount Plate
More Details Less Details
Width 3"
Height 13"
Temp Range -20°F to 180°F
Rig Type Swivel
Brake No Brake
Frame Zinc Plated Steel
Hamilton Aerospace S-AEZFFM-83FSB Spring Loaded Forge Master Swivel Caster 8" x 3" Forged Steel...
Shop Product
TieredPricing
Hamilton Aerospace S-AEZFFM-63FSB Swivel Caster - 6x3" Forged Steel Wheel with 3/4" Precision Ball Bearing - Heavy-Duty for Aerospace Hamilton
Made to Order · 4-6 Wk
Hamilton S-AEZFFM-63FSB 6" x 3" Forged Steel Spring Loaded Swivel Caster
Part # S-AEZFFM-63FSB
$1,615.00
Volume pricing available
Plate
Diameter 6"
Mount Plate
More Details Less Details
Width 3"
Height 12"
Temp Range -20°F to 180°F
Rig Type Swivel
Brake No Brake
Frame Zinc Plated Steel
S-AEZFFM-63FSB Hamilton Aerospace Spring Loaded Forge Master Swivel Caster 6" x 3" Forged Steel...
Shop Product
TieredPricing
Hamilton Aerospace Spinfinity Swivel Caster: 10" x 3" Forged Steel Wheel, 3/4" Precision Ball Bearing – Heavy Duty Aerospace Caster Hamilton
Made to Order · 4-6 Wk
Hamilton S-AEZFFM-13FSB 10" x 3" Forged Steel Swivel Spring Loaded Caster
Part # S-AEZFFM-13FSB
$1,889.00
Volume pricing available
Plate
Diameter 10"
Mount Plate
More Details Less Details
Width 3"
Height 14"
Temp Range -20°F to 180°F
Rig Type Swivel
Brake No Brake
Frame Zinc Plated Steel
Hamilton Aerospace Spring Loaded Spinfinity (FM) Swivel Caster 10" x 3" Forged Steel Wheel...
Shop Product
TieredPricing
Hamilton Aerospace R-AEZFFM-83FSB - 8"x3" Forged Steel Wheel Rigid Caster with 3/4" Precision Ball Bearing for Aerospace Applications Hamilton
Made to Order · 4-6 Wk
Hamilton R-AEZFFM-83FSB 8"x3" Forged Steel Rigid Spring Loaded Caster
Part # R-AEZFFM-83FSB
$1,753.00
Volume pricing available
Plate
Diameter 8"
Mount Plate
More Details Less Details
Width 3"
Height 13"
Temp Range -20°F to 180°F
Rig Type Rigid
Brake No Brake
Frame Zinc Plated Steel
Hamilton Aerospace R-AEZFFM-83FSB Spring Loaded Forge Master Rigid Caster 8" x 3" Forged Steel...
Shop Product
2775 lbs
TieredPricing
Hamilton Aerospace R-AEZFFM-63FSB Rigid Caster - 6x3" Forged Steel Wheel with 3/4" Precision Ball Bearing - Heavy-Duty for Aerospace Hamilton
Made to Order · 4-6 Wk
Hamilton R-AEZFFM-63FSB 6" x 3" Forged Steel Rigid Caster – 2775 lb
Part # R-AEZFFM-63FSB
$1,347.00
Volume pricing available
Plate
Load rating
2775 lbs
Diameter 6"
Capacity 2775 lbs
Mount Plate
More Details Less Details
Width 3"
Height 12"
Temp Range -20°F to 180°F
Rig Type Rigid
Brake No Brake
Frame Zinc Plated Steel
R-AEZFFM-63FSB Hamilton Aerospace Spring Loaded Forge Master Rigid Caster 6" x 3" Forged Steel...
Shop Product
TieredPricing
Hamilton Aerospace Rigid Caster: 10" x 3" Forged Steel Wheel, 3/4" Precision Ball Bearing – Heavy Duty Aerospace Caster Hamilton
Made to Order · 4-6 Wk
Hamilton R-AEZFFM-13FSB 10" x 3" Forged Steel Rigid Spring Loaded Caster
Part # R-AEZFFM-13FSB
$1,858.00
Volume pricing available
Plate
Diameter 10"
Mount Plate
More Details Less Details
Width 3"
Height 14"
Temp Range -20°F to 180°F
Rig Type Rigid
Brake No Brake
Frame Zinc Plated Steel
Hamilton Aerospace Spring Loaded (FM) Rigid Caster 10" x 3" Forged Steel Wheel |...
Shop Product

Hamilton Spring Loaded | AEZFFM Casters with Forged Steel Wheels

Top-Notch Forged Steel Wheels | Advanced Spring-Loaded Mechanism

Experience Superior Mobility with Hamilton's AEZFFM Casters

The Hamilton Spring Loaded AEZFFM Casters are engineered to perfection, offering enhanced mobility and durability. With state-of-the-art forged steel wheels, they guarantee unmatched load-bearing capabilities. Their innovative spring-loaded mechanism ensures reduced vibration, making them a top choice for industrial applications.

Why Hamilton AEZFFM Casters are Best for Heavy-Duty Uses

Opt for Hamilton's AEZFFM series and benefit from decades of expertise in caster technology. Ideal for heavy-duty industrial settings, these casters provide an optimal balance between performance and durability. Trust in Hamilton for superior mobility solutions.

Need Assistance? Hamilton's Caster Experts are Here to Help

Thinking about integrating the Hamilton AEZFFM Casters into your setup? Connect with our team of seasoned Caster Specialists for guidance. Available weekdays from 8 am - 5 pm, we're committed to providing you with tailored solutions for your mobility needs.
