Polyurethane Brake Casters

This collection holds Polyurethane Brake Casters, built for shop carts, equipment, and material handling carts that move heavier loads. Casters in this collection range from 90 to 1,500 lb per caster. Wheels in this category range from 2-1/2 up to 8 inches in diameter with 1-1/4 to 10 in tread widths. The collection includes swivel, rigid, and brake models. Kingpinless swivels hold up better under shock and repeat loads. Polyurethane (poly or urethane) treads are quiet, floor safe, and resist water and many chemicals. Metal wheels roll with low effort and handle debris and heat. They are loud and can mark finished floors. Semi steel (gray iron) rolls with low effort and shrugs off debris. It is loud and can mark finished floors. Match the stem size and thread before you order. Choose swivel casters when the cart must turn in place and rigid casters for straight travel. Polyurethane aisle: polyurethane casters. Wheel hub: replacement wheels.

Polyurethane brake casters by tread

Tread Core Wheel sizes Rated per caster Listed temperature Where it fits
Polyurethane Polyolefin and Cast iron 2-1/2 to 8 in 250 to 1,500 lb -45°F to 180°F quiet, floor-friendly and long wearing

Ratings are for single casters of polyurethane brake casters, from product fields [S1].

Wheel sizes

Wheel Treads Rated
3 x 1-1/4 in polyurethane 300 lb
4 x 1-1/4 in polyurethane 275 to 350 lb
4 x 1-9/16 in polyurethane 550 to 615 lb
4 x 2 in polyurethane 600 to 1,000 lb
5 x 1-1/4 in polyurethane 250 to 350 lb
5 x 2 in polyurethane 600 to 1,200 lb
6 x 2 in polyurethane 900 to 1,250 lb
8 x 2 in polyurethane 660 to 1,500 lb

Choosing polyurethane brake casters

  1. Load: divide the loaded weight by three for a four-caster cart [S2]. Among polyurethane brake casters, a 1,000 lb caster then suits about 3,000 lb, and the strongest at 1,500 lb about 4,500 lb.
  2. Mount: most polyurethane brake casters use a 4 x 4-1/2 in top plate; 2-1/2 x 3-5/8 in and 2-3/8 x 3-5/8 in plates are listed too; measure bolt hole centers on the old plate and compare.
  3. Floor: on polyurethane brake casters, polyurethane protects finished floors and runs quietly; check the rating if the cart also crosses rough concrete.
  4. Rig: swivel and rigid polyurethane brake casters are listed, with top lock brake, side lock brake and total lock brake options.

Polyurethane brake casters questions

How much weight can polyurethane brake casters carry?

Single polyurethane brake casters are rated 250 to 1,500 lb; most fall between 600 and 1,000 lb.

What top plate do polyurethane brake casters use?

Most polyurethane brake casters use 4 x 4-1/2 in. Other plates on polyurethane brake casters: 2-1/2 x 3-5/8 in and 2-3/8 x 3-5/8 in.

What wheel material is most common on polyurethane brake casters?

Polyurethane leads on polyurethane brake casters, rated 250 to 1,500 lb per caster.

Sources

  • [S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
  • [S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
