Polyurethane Plate Casters

This collection holds Polyurethane Plate Casters, built for heavy equipment, dies, molds, and plant carts that move very heavy loads. Casters in this collection range from 100 to 3,500 lb per caster. Wheels in this category range from 2 up to 12 inches in diameter with 1-1/4 to 10 in tread widths. The collection includes swivel, rigid, and brake models. Kingpinless swivels hold up better under shock and repeat loads. Dual wheel casters split the load over two wheels and swivel with less effort under heavy loads. Polyurethane (poly or urethane) treads are quiet, floor safe, and resist water and many chemicals. Semi steel (gray iron) rolls with low effort and shrugs off debris. It is loud and can mark finished floors. Nylon rolls easily, resists water and many chemicals, and is hard, so it is loud on rough floors. Choose swivel casters when the cart must turn in place and rigid casters for straight travel. Polyurethane aisle: polyurethane casters. Wheel hub: replacement wheels.

Shop by wheel material

3 types

Rubber and polyurethane favor floor protection; phenolic and steel favor heavy capacity. Compare materials →

Polyurethane plate casters by tread

Tread Core Wheel sizes Rated per caster Listed temperature Where it fits
Polyurethane Polyolefin and Cast iron 3 to 10 in 250 to 2,500 lb -45°F to 180°F quiet, floor-friendly and long wearing
Nylon 4, 5, 6, 8 and 10 in 700 to 3,000 lb Up to 180°F low rolling effort on smooth floors, handles wet areas
Cast iron 8 in 2,500 lb -40°F to 180°F heat, chips and heavy loads on rough floors

Ratings are for single casters of polyurethane plate casters, from product fields [S1].

Wheel sizes

Wheel Treads Rated
3 x 1-1/4 in polyurethane 250 to 300 lb
4 x 1-1/4 in polyurethane 275 to 440 lb
4 x 2 in polyurethane and nylon 600 to 1,250 lb
5 x 1-1/4 in polyurethane 300 to 400 lb
5 x 2 in polyurethane and nylon 750 to 1,250 lb
6 x 2 in polyurethane and nylon 900 to 1,800 lb
6 x 3 in polyurethane and nylon 2,000 to 3,000 lb
8 x 2 in polyurethane and nylon 800 to 1,500 lb

Choosing polyurethane plate casters

  1. Load: plan on three casters carrying a four-caster cart [S2]; at 1,200 lb each, a common rating here, that is about 3,600 lb, and the 3,000 lb top rating covers about 9,000 lb.
  2. Mount: most polyurethane plate casters use a 4 x 4-1/2 in top plate; 4-1/2 x 6-1/4 in and 2-3/8 x 3-5/8 in plates are listed too; match the bolt holes on your frame to the plate before ordering.
  3. Floor: on polyurethane plate casters, polyurethane is kinder to tile and finished floors; nylon and cast iron roll easier under heavy loads on smooth concrete.
  4. Rig: swivel and rigid polyurethane plate casters are listed, with total lock brake, top lock brake and side lock brake options.

Polyurethane plate casters questions

How much weight can polyurethane plate casters carry?

Single polyurethane plate casters are rated 145 to 3,000 lb; most fall between 400 and 1,200 lb.

What top plate do polyurethane plate casters use?

Most polyurethane plate casters use 4 x 4-1/2 in. Other plates on polyurethane plate casters: 4-1/2 x 6-1/4 in and 2-3/8 x 3-5/8 in.

What wheel material is most common on polyurethane plate casters?

Polyurethane leads on polyurethane plate casters, rated 250 to 2,500 lb per caster. Among polyurethane plate casters, nylon is next at 700 to 3,000 lb.

Sources

  • [S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
  • [S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
