Medium Heavy Duty Casters | to 1,500 lb

This collection holds Medium Heavy Duty Casters with polyurethane, nylon and rubber wheels, built for shop carts, equipment, and material handling carts that move heavier loads. Casters in this collection range from 300 to 2,000 lb per caster. Wheels in this category range from 3 up to 10 inches in diameter with 1 to 2-1/2 in tread widths. The collection includes swivel, rigid, and brake models. Flanged and V groove track wheels ride on rail or angle iron track for straight line travel. Polyurethane (poly or urethane) treads are quiet, floor safe, and resist water and many chemicals. Nylon rolls easily, resists water and many chemicals, and is hard, so it is loud on rough floors. Rubber wheels are quiet, cushion the load, and protect floors. Soft rubber or TPR is the better pick when the floor has chips or grit. Choose swivel casters when the cart must turn in place and rigid casters for straight travel. Polyurethane aisle: polyurethane casters. Wheel hub: replacement wheels.

Shop by type

7 types

Wheel = wheel diameter · capacity is per caster.

Durastar medium heavy duty casters by tread

Tread	Core	Wheel sizes	Rated per caster	Listed temperature	Where it fits
Polyurethane	Polyolefin and Aluminum	4, 5, 6, 8 and 10 in	700 to 1,500 lb	-45°F to 180°F	quiet, floor-friendly and long wearing
Rubber	Polyolefin and Nylon	4, 5, 6, 8 and 10 in	350 to 850 lb	-45°F to 180°F	cushioned and quiet on finished floors
Nylon		4, 5, 6, 8 and 10 in	400 to 1,500 lb	Up to 180°F	low rolling effort on smooth floors, handles wet areas
Polyolefin		4, 5, 6 and 8 in	500 to 1,200 lb	-45°F to 180°F	wet and chemical areas, light to medium loads
Phenolic		4, 5, 6 and 8 in	800 to 1,400 lb	Up to 250°F	hard and easy rolling on smooth, dry floors
Semi-steel		4, 5, 6, 8 and 10 in	700 to 1,500 lb	-45°F to 600°F	rough floors, heat and heavy loads
Ductile iron	Steel	4, 5, 6, 8 and 10 in	1,250 to 1,500 lb	-45°F to 800°F	heavy loads with better impact strength than cast iron

Ratings are for single casters of Durastar medium heavy duty casters, from product fields [S1].

Wheel sizes

Wheel	Treads	Rated
3 x 1-13/16 in	nylon, polyolefin and polyurethane	500 to 1,000 lb
4 x 2 in	polyurethane, rubber and nylon	300 to 1,500 lb
5 x 2 in	polyurethane, rubber and nylon	350 to 1,500 lb
6 x 2 in	polyurethane, rubber and nylon	500 to 2,000 lb
6 x 2-1/2 in	rubber, steel and semi-steel	600 to 1,500 lb
8 x 2 in	polyurethane, rubber and nylon	600 to 2,000 lb
8 x 2-1/2 in	rubber, semi-steel and polyurethane	700 to 1,500 lb
10 x 2-1/2 in	rubber, polyurethane and semi-steel	1,000 to 1,500 lb

Choosing Durastar medium heavy duty casters

Load: divide the loaded weight by three for a four-caster cart [S2]. Among Durastar medium heavy duty casters, a 1,200 lb caster then suits about 3,600 lb, and the strongest at 1,500 lb about 4,500 lb.
Mount: most Durastar medium heavy duty casters use a 4 x 4-1/2 in top plate; 4-1/2 x 6-1/4 in plates are listed too; match the bolt holes on your frame to the plate before ordering.
Floor: on Durastar medium heavy duty casters, polyurethane and rubber are kinder to tile and finished floors; nylon, polyolefin, phenolic, semi-steel and ductile iron roll easier under heavy loads on smooth concrete.
Rig: swivel and rigid Durastar medium heavy duty casters are listed.
Heat: among Durastar medium heavy duty casters, the highest listed range is -45°F to 800°F on ductile iron; check the temperature field on each listing before oven or hot-room use.

Related to Durastar medium heavy duty casters: industrial casters, 04 series and X05 series.

Durastar medium heavy duty casters questions

How much weight can Durastar medium heavy duty casters carry?

Single Durastar medium heavy duty casters are rated 350 to 1,500 lb; most fall between 600 and 1,200 lb.

What top plate do Durastar medium heavy duty casters use?

Most Durastar medium heavy duty casters use 4 x 4-1/2 in. Other plates on Durastar medium heavy duty casters: 4-1/2 x 6-1/4 in.

What wheel material is most common on Durastar medium heavy duty casters?

Polyurethane leads on Durastar medium heavy duty casters, rated 700 to 1,500 lb per caster. Among Durastar medium heavy duty casters, rubber is next at 350 to 850 lb.

Jordan Wilson, CasterHQ · reviewed October 20, 2026 · 844-439-4335 · info@casterhq.com

Sources

[S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
[S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
