The CasterHQ HTGFN5X112 is a 5" diameter x 1-1/2" wide glass-filled nylon wheel rated 700 lb per wheel, running 475°F continuously and 550°F intermittently. Glass-filled nylon runs in both dry and moist heat, which is what separates it from phenolic, and most buyers specify it for the moist side: bakery oven racks, smokehouse trucks, proof boxes, autoclave carts, and steam wash-down lines where a polyurethane or rubber wheel would soften, delaminate, or flat-spot. It is impervious to most chemicals, solvents, oils, salt, alkalines, and water, and it holds capacity through repeated heat cycles.
| Wheel Diameter | 5" |
|---|---|
| Tread Width | 1-1/2" |
| Tread Face | Flat |
| Wheel Material | Glass-Filled Nylon |
| Durometer | 85D ± 5 |
| Load Capacity | 700 lb per wheel |
| Temperature Rating | 475°F continuous / 550°F intermittent / -40°F low |
| Heat Type | Dry and moist heat |
| Bearing | Plain Bore |
| Spanner Bushing | Yes |
| Part Number | HTGFN5X112 |
Capacity is rated at room temperature. Under sustained maximum heat or sustained cold, de-rate capacity by 20%.
Need the exact bore and hub length for your rig? Send us your axle size and we will confirm fitment before you order.
Engineer Tip: Glass-filled nylon has a hard tread and belongs on smooth floors. On rough concrete or over floor obstructions the service life drops fast, and the impact loading is what cracks the hub, not the heat. Where the cart crosses a threshold or a floor drain grate, shield the wheel from direct heat intake and step up to a 2" tread instead of adding capacity elsewhere.
It replaces the wheels on carts, racks, and trucks that live inside heat. The 5" x 1-1/2" size is the common swap on bakery oven racks and smokehouse trucks where a 4" wheel no longer clears floor debris or the operator wants easier roll-out under load. At 700 lb per wheel, a four-wheel rack carries 2,800 lb theoretical, and specifying to roughly 75% of that leaves margin for shock loading at door thresholds.
700 lb per wheel at room temperature. De-rate 20% to 560 lb per wheel for sustained operation at maximum rated temperature or in sustained sub-freezing service. Rate the assembly on three wheels, not four, since floors are rarely flat enough to load all four evenly.
This wheel ships plain bore with a spanner bushing. It is a wheel only, not a complete caster, so the brake lives in the rig you mount it to. If you need the finished assembly, the 5" x 2" High Temp Glass-Filled Nylon Swivel Caster is available with top-locking brake and bolt-on swivel lock on a 4" x 4-1/2" plate.
Glass-filled nylon runs in both dry and moist heat. High-temp phenolic runs dry heat only. That is the whole decision. Phenolic absorbs water in steam, humid bake, and wash-down environments, then swells, delaminates, and chips, so it has no place in a smokehouse, autoclave, proof box, or sanitation line. Glass-filled nylon handles those and handles dry radiant heat as well, which makes it the wider-envelope wheel and the safer spec when one cart sees more than one condition. Most buyers land on nylon for moist-heat duty specifically, but if your only concern is dry radiant heat you can compare high-temp phenolic wheels on cost.
Same family, different footprint and resin grade. The 4" x 1-1/2" high temp glass-filled nylon wheel is a moist-heat wheel rated 300 lb and 425°F for 30 minutes maximum. This 5" runs the higher-grade resin at 475°F continuous. Step to the 5" x 2" glass-filled nylon wheel at 1,000 lb when the load is the constraint rather than the clearance.
475°F continuously and 550°F intermittently, with a low-end rating of -40°F.
Yes. Glass-filled nylon handles both dry and moist heat. High-temp phenolic is a dry-heat-only wheel, which is why nylon is the safer spec when a cart sees more than one condition.
700 lb per wheel at room temperature. De-rate by 20% for sustained maximum heat or sustained cold.
Wheel only. It ships plain bore with a spanner bushing and mounts into your existing rig.
Yes. Glass-filled nylon is impervious to water, steam, most chemicals, solvents, oils, salt, and alkalines, which is why it outlasts phenolic in sanitation-heavy plants.
Yes. It is non-marking and non-sparking, and it runs quieter than a steel or cast iron wheel.
Yes. Quantity discounts start at 50 pieces, and for rack-fleet or plant-wide quantities request a bulk quote and our team will spec and price the full set.
Order processing
In stock. Orders placed before 12pm CT (Mon–Fri) typically ship the same or next business day from our Mansfield, TX warehouse.
Shipping method
Smaller orders ship parcel (UPS/FedEx Ground). Heavy or bulk quantities consolidate to LTL freight. The method and final cost are shown before payment, so there are no post-checkout adjustments.
Payment & procurement terms
New to CasterHQ? Open an account or request terms and send your resale or tax-exemption certificate before ordering so it is applied at checkout.
Volume pricing & quotes
Quantity discounts apply automatically — no codes needed. For large, recurring, or custom requirements, request a bulk quote and our team will confirm pricing, lead time, and total landed freight upfront.
Returns & warranty
Stock items carry a 30-day return policy in unused, resalable condition. Made-to-order and custom items are non-returnable once production starts. All products carry the manufacturer's warranty against defects.
Central & Southern U.S.: typically 1–2 business days
East & West Coasts: typically 2–3 business days
Remote areas and freight deliveries may take longer.
For pallet freight, scheduled releases, or blanket purchase orders, contact our team and we'll confirm total landed cost before you commit. Direct line: 844-439-4335.
This 5" x 1-1/2" High Temp Glass-Filled Nylon Wheel – 700 lb is rated to 700 lbs per wheel. Divide the total load across the number of wheels in your rig and keep working loads within about 75-80% of the rating for continuous use.
This is a Nylon wheel. Nylon resists chemicals and moisture and carries high loads, which suits washdown and wet environments.
5" diameter x 1-1/2" tread width. Verify your axle diameter and hub/bore length against your existing wheel before ordering.
Yes. Most wheels can be paired with a swivel or rigid rig to build a complete caster. Tell us your mount and load and we will spec the rig - request it on our bulk pricing page.
Rated for Up to 550°F. Operating outside the rated range can shorten wheel life and reduce capacity.
We accept purchase orders and offer Net 30 on approved accounts, ACH, and all major cards, plus tax-exempt ordering with a resale or exemption certificate. Volume discounts apply automatically; request a bulk quote for large or recurring orders. Stock items carry a 30-day return policy in unused condition (made-to-order items are non-returnable once production starts).
