Up to 350 lbs
Up to 6,000 lbs
Up to 16,000 lbs
Up to 40,000 lbs
High-capacity loads
Shock absorbing
Corrosion resistant
Outdoor / rough terrain
OEM replacements
All measurements indicate the wheel diameter by the tread width.
The below capacity ranges indicate the working (dynamic) load that each caster will support. A safety factor should be included in your formula to determine your required load rating per caster.
W/(C-1)=R W is total weight needed to move. C is total number of casters required. R is ideal load rating, with safety factor built in. Divide the total load weight by one less caster than you will use to safely determine load rating.
Plate dimensions shown are overall mounting plate size.
When replacing existing casters, select the closest plate size and verify bolt-hole compatibility.
BHP = Bolt Hole Pattern, shown under each plate.
















































The 28 Series Towable Albion Casters are engineered for exceptional durability and ease of movement. With a robust construction combining heavy-duty steel and a polyurethane wheel, these casters are designed to handle up to 800 pounds, making them ideal for heavy-duty applications. The 4-inch diameter wheel ensures smooth and stable operation, while the top plate mount provides secure attachment to a variety of equipment. Whether you need mobility for industrial carts, trailers, or other towable equipment, these casters offer both strength and reliability.
Enhance your equipment's performance and mobility with the 28 Series Towable Albion Casters. Experience superior strength and smooth operation for your heavy-duty needs.
