Hamilton Extra Heavy Duty EHD Casters

Custom made to order. All sales final.

Each Hamilton product is custom manufactured for your order (lead time is shown on each product page). Please confirm all specs before checkout, since made-to-order items aren't eligible for returns, exchanges or refunds. Need help? Call 844-439-4335 or email info@casterhq.com and we'll verify fit for you.

These Hamilton EHD extra heavy duty casters fit heavy equipment, dies, molds, and plant carts that move very heavy loads. Casters in this collection range from 1,600 to 5,000 lb per caster. Wheels are 6 to 12 x 2-1/2 and 3 in swivel and rigid models. Wheel options include polyurethane, nylon, phenolic, and forged steel, so match the tread to the floor and the load. Match plate size, bolt pattern, and overall height before you order. Choose swivel casters when the cart must turn in place and rigid casters for straight travel. Read the listing for the exact wheel size, overall height, and mount shown. Confirm the load rating printed on the title before you order. Measure the old wheel or caster before you buy. Check the floor type and the heaviest load the cart will carry before you choose. Heavy duty hub: heavy duty casters. Plate aisle: plate casters.

Shop by type

11 types

Wheel = wheel diameter · capacity is per caster.

Hamilton Extra Heavy Duty EHD Casters: buying guide

Hamilton extra heavy duty EHD casters by tread

Tread Core Wheel sizes Rated per caster Listed temperature Where it fits
Polyurethane Cast iron and Aluminum 6, 8, 10 and 12 in 1,600 to 5,000 lb -5°F to 160°F quiet, floor-friendly and long wearing
Cast iron 6, 8, 10 and 12 in 2,200 to 2,600 lb -40°F to 320°F heat, chips and heavy loads on rough floors
Steel 6, 8 and 10 in 3,500 to 5,000 lb -40°F to 320°F heavy loads and track
Phenolic 6, 8 and 10 in 1,800 to 2,500 lb Up to 250°F hard and easy rolling on smooth, dry floors
Nylon 6, 8 and 10 in 5,000 lb low rolling effort on smooth floors, handles wet areas

Ratings are for single casters of Hamilton extra heavy duty EHD casters, from product fields [S1].

Wheel sizes

Wheel Treads Rated
6 x 2-1/2 in phenolic, cast iron and steel 1,600 to 3,500 lb
6 x 3 in polyurethane, steel and nylon 2,200 to 5,000 lb
8 x 2-1/2 in phenolic, cast iron and polyurethane 2,000 to 2,500 lb
8 x 3 in polyurethane, nylon and cast iron 2,500 to 5,000 lb
10 x 2-1/2 in phenolic, cast iron and polyurethane 2,500 lb
10 x 3 in polyurethane, nylon and cast iron 2,600 to 5,000 lb
12 x 3 in polyurethane and cast iron 2,500 to 5,000 lb

Choosing Hamilton extra heavy duty EHD casters

  1. Load: plan on three casters carrying a four-caster cart [S2]; at 4,550 lb each, a common rating here, that is about 13,650 lb, and the 5,000 lb top rating covers about 15,000 lb.
  2. Mount: most Hamilton extra heavy duty EHD casters use a 6-1/8 x 7-1/2 in top plate; 5-1/2 x 7-1/2 in plates are listed too; measure bolt hole centers on the old plate and compare.
  3. Floor: on Hamilton extra heavy duty EHD casters, polyurethane is kinder to tile and finished floors; cast iron, steel, phenolic and nylon roll easier under heavy loads on smooth concrete.
  4. Rig: swivel and rigid Hamilton extra heavy duty EHD casters are listed.
  5. Heat: among Hamilton extra heavy duty EHD casters, the highest listed range is -40°F to 320°F on cast iron; check the temperature field on each listing before oven or hot-room use.

Hamilton extra heavy duty EHD casters questions

How much weight can Hamilton extra heavy duty EHD casters carry?

Single Hamilton extra heavy duty EHD casters are rated 1,600 to 5,000 lb; most fall between 2,500 and 4,550 lb.

What top plate do Hamilton extra heavy duty EHD casters use?

Most Hamilton extra heavy duty EHD casters use 6-1/8 x 7-1/2 in. Other plates on Hamilton extra heavy duty EHD casters: 5-1/2 x 7-1/2 in.

What wheel material is most common on Hamilton extra heavy duty EHD casters?

Polyurethane leads on Hamilton extra heavy duty EHD casters, rated 1,600 to 5,000 lb per caster. Among Hamilton extra heavy duty EHD casters, cast iron is next at 2,200 to 2,600 lb.

Sources

  • [S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
  • [S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
