All measurements indicate the wheel diameter by the tread width.
The below capacity ranges indicate the working (dynamic) load that each caster will support. A safety factor should be included in your formula to determine your required load rating per caster.
W/(C-1)=R W is total weight needed to move. C is total number of casters required. R is ideal load rating, with safety factor built in. Divide the total load weight by one less caster than you will use to safely determine load rating.
Plate dimensions shown are overall mounting plate size.
When replacing existing casters, select the closest plate size and verify bolt-hole compatibility.
BHP = Bolt Hole Pattern, shown under each plate.
Rubber and polyurethane favor floor protection; phenolic and steel favor heavy capacity. Compare materials →
























| Tread | Core | Wheel sizes | Rated per caster | Listed temperature | Where it fits |
|---|---|---|---|---|---|
| Polyurethane | Cast iron and Aluminum | 4 to 18 in | 600 to 12,500 lb | Up to 180°F | quiet, floor-friendly and long wearing |
| Nylon | 4, 5, 6 and 8 in | 800 to 1,400 lb | Up to 180°F | low rolling effort on smooth floors, handles wet areas |
Ratings are for single casters of polyurethane kingpinless casters, from product fields [S1].
| Wheel | Treads | Rated |
|---|---|---|
| 4 x 2 in | polyurethane and nylon | 450 to 1,200 lb |
| 5 x 2 in | polyurethane and nylon | 600 to 1,500 lb |
| 6 x 2 in | polyurethane and nylon | 900 to 1,800 lb |
| 6 x 3 in | polyurethane | 2,400 to 7,600 lb |
| 8 x 2 in | polyurethane and nylon | 1,000 to 2,000 lb |
| 16 x 5 in | polyurethane | 9,700 lb |
| 16 x 7 in | polyurethane | 8,200 to 9,800 lb |
| 18 x 9 in | polyurethane | 12,500 to 15,000 lb |
Related to polyurethane kingpinless casters: industrial casters.
Single polyurethane kingpinless casters are rated 600 to 12,500 lb; most fall between 1,000 and 2,000 lb.
Most polyurethane kingpinless casters use 4 x 4-1/2 in. Other plates on polyurethane kingpinless casters: 8-1/2 x 8-1/2 in and 5-1/4 x 7-1/4 in.
Polyurethane leads on polyurethane kingpinless casters, rated 600 to 12,500 lb per caster. Among polyurethane kingpinless casters, nylon is next at 800 to 1,400 lb.
