Fixture & Display Casters and Wheels

This collection holds Fixture & Display Casters and Wheels with polyurethane, rubber and polyolefin wheels, built for shop carts, equipment, and material handling carts that move heavier loads. Casters in this collection range from 80 to 800 lb per caster. Wheels in this category range from 2 up to 5 inches in diameter with 1 to 2-3/8 in tread widths. The collection includes swivel and brake models. Dual wheel casters split the load over two wheels and swivel with less effort under heavy loads. Polyurethane (poly or urethane) treads are quiet, floor safe, and resist water and many chemicals. Rubber wheels are quiet, cushion the load, and protect floors. Polyolefin is light, low cost, and resists water and many chemicals. It is hard, so it is loud on rough floors. Soft rubber or TPR is the better pick when the floor has chips or grit. Match the stem size and thread before you order. Polyurethane aisle: polyurethane casters. Wheel hub: replacement wheels.

Shop by type

6 types

Wheel = wheel diameter · capacity is per caster.

Fixture & display casters and wheels by tread

Tread	Core	Wheel sizes	Rated per caster	Listed temperature	Where it fits
Rubber	Polyolefin	2, 2-1/2, 3, 4 and 5 in	90 to 300 lb	-45°F to 180°F	cushioned and quiet on finished floors
Polyolefin		2, 3, 4 and 5 in	80 to 500 lb	-45°F to 180°F	wet and chemical areas, light to medium loads
Polyurethane	Polyolefin	2, 2-1/2, 3, 4 and 5 in	90 to 300 lb	-45°F to 180°F	quiet, floor-friendly and long wearing
Phenolic		3, 4 and 5 in	300 to 800 lb	-45°F to 180°F	hard and easy rolling on smooth, dry floors
Nylon		3 in	800 lb	-40°F to 250°F	low rolling effort on smooth floors, handles wet areas

Ratings are for single casters of fixture & display casters and wheels, from product fields [S1].

Wheel sizes

Wheel	Treads	Rated
2 x 13/16 in	rubber and polyolefin	80 to 300 lb
2 x 7/8 in	rubber and polyurethane	90 to 100 lb
2 x 1 in	polyolefin	80 to 350 lb
2-1/2 x 7/8 in	rubber and polyurethane	100 lb
3 x 13/16 in	rubber	100 lb
3 x 1-1/4 in	polyurethane, phenolic and polyolefin	250 to 300 lb
4 x 1-1/4 in	polyurethane, rubber and phenolic	250 to 300 lb
5 x 1-1/4 in	polyurethane, rubber and phenolic	300 lb

Choosing fixture & display casters and wheels

Load: plan on three casters carrying a four-caster cart [S2]; at 300 lb each, a common rating here, that is about 900 lb, and the 800 lb top rating covers about 2,400 lb.
Stem: the most common stem on fixture & display casters and wheels is 1 in; 7/8 in and 3/8-16 x 1 in also appear; measure thread size and length, or the tube inside diameter, on the old caster.
Floor: on fixture & display casters and wheels, rubber and polyurethane are kinder to tile and finished floors; polyolefin, phenolic and nylon roll easier under heavy loads on smooth concrete.
Rig: swivel fixture & display casters and wheels are listed, with side lock brake and top lock brake options.

Related to fixture & display casters and wheels: industrial casters, low profile casters and heavy-duty compact wheels and 3/8 in threaded stem casters.

Fixture & display casters and wheels questions

How much weight can fixture & display casters and wheels carry?

Single fixture & display casters and wheels are rated 80 to 800 lb; most fall between 180 and 300 lb.

What stem do fixture & display casters and wheels use?

Most fixture & display casters and wheels list 1 in. Others: 7/8 in and 3/8-16 x 1 in.

What wheel material is most common on fixture & display casters and wheels?

Rubber leads on fixture & display casters and wheels, rated 90 to 300 lb per caster. Among fixture & display casters and wheels, polyolefin is next at 80 to 500 lb.

Jordan Wilson, CasterHQ · reviewed October 20, 2026 · 844-439-4335 · info@casterhq.com

Sources

[S1] CasterHQ product fields (rated load, diameter, width, wheel and core material, temperature range, mount) and product descriptions for the items on this page, pulled October 20, 2026.
[S2] Preferred Equipment casters and wheels quick guide PDF (prefeq.com): load sizing on one less caster, wheel types and floor notes.
